G1003 HART to Modbus Gateway
G1003
G1003
G1003
G1003
G1003 HART to Modbus Gateway
G1003
G1003
G1003
G1003

G1003 HART to Modbus Gateway

G1003

Product Overview

The G1003 is a Microcyber G Series DIN-rail protocol conversion gateway that enables efficient protocol conversion from HART to Modbus RTU. It helps users seamlessly integrate existing HART devices into a Modbus network. Featuring easy installation, strong compatibility, and simple configuration, it greatly improves fieldbus system integration efficiency and quickly meets system upgrade requirements.

No certification
Get a Quote
Application Cases
Output Signal Modbus
Protocol Version HART 5, HART 6, HART 7
Gateway Supply Voltage (9~30)VDC
Gateway Supply Current ≤60mA
Input Signal HART
HART Slave Device Max Connections 15
Modbus Slave Address Range 1-247
Modbus Supported Baud Rates (300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200)bps
Modbus Supported Commands 3, 4, 6, 16
Startup Time ≤5s
EMC IEC 61326 (GB/T 18268)
Isolation Voltage 500VAC
HART Interface Input Impedance ≥5kΩ
Display LED indicator
Operating Temperature (-20~70)℃
Humidity Range (5~95)%RH
Storage Temperature (-20~70)℃
Protection Level IP20
Housing Material ABS
Electrical Interface Pluggable terminal block
Dimensions (114.5 × 99 × 22.5)mm
Mounting DIN rail
Weight Approx. 0.15kg
  • Quickly meet field application needs: Help system integrators quickly achieve seamless conversion from HART to Modbus to meet on-site application requirements.
  • Easy to install: Microcyber G-series gateways support DIN rail mounting for simple and convenient installation.
  • Comply with mainstream control systems: Microcyber G-series gateways have been tested and verified with major control systems from Siemens, Emerson, Schneider Electric, ABB, Honeywell, Rockwell Automation, and others.
  • Simple configuration: With the dedicated Modbus configuration tool, users can freely and flexibly set various module parameters according to application requirements.
  • Simple application: The gateway reads and writes parameter data from HART devices through the HART interface and automatically converts it into Modbus variables and related parameters for communication with the Modbus master station.
  • Wide range of applications: Ideal for system integrators building Modbus communication systems, as well as manufacturers of measurement instruments, detectors, and analyzers that need to connect HART instruments to Modbus networks.
